TP-LINK TL-SG1008PE 8-PORT GIGABIT SWITCH

TP-LINK TL-SG1008PE 8-PORT GIGABIT SWITCH

The TP-LINK TL-SG1008PE 8-PORT is an 8-port gigabit switch that provides a simple and cost-effective way to expand your wired network. It features 8 gigabit Ethernet ports, which allow for high-speed data transfers and seamless connectivity for your devices.

One of the key features of the TL-SG1008PE is its Power over Ethernet (PoE) capability. This means that it can supply power to compatible devices, such as;

• IP cameras,
• VoIP phones,
• wireless access points,

using the Ethernet cables, eliminating the need for separate power cables.

The switch also supports IEEE 802.3x flow control for full-duplex mode and back pressure for half-duplex mode, ensuring reliable data transfer. It also has a compact and sturdy metal case design, making it suitable for desktop or rack-mount installation.

Overall, the TP-LINK TL-SG1008PE is a reliable and efficient solution for expanding your network and providing power to PoE-enabled devices.

TP-Link TL-SG1008PE is an 8-Port Gigabit Desktop/Rack mountable Switch with all 8 ports supporting the PoE standard.

It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable.

With a total power budget of 124W, up to 30W per port, TL-SG1008PE can power more high-powered devices such as;

• wireless Access Points (APS),
• IP Cameras,
•  IP Phones.

Moreover, with innovative energy-efficient technology, the TL-SG1008PE can save up to 75% of the power consumption, making it an eco-friendly solution for your business network.

TP-LINK TL-SG1008PE 8-PORT Key Features.

• 8 10/100/1000Mbps RJ45 ports
• Equipped with 8 PoE supported ports to transfer data and power over a single cable
• Works with IEEE 802.3af/at compliant devices, expanding home and office networks
• Innovative energy-efficient technology reduces power output by up to 75%
• Plug and play design, no configuration required.

How This Product Works

All 8 ports of TL-SG1008PE support Power over Ethernet Plus (PoE ) standard which can automatically detect and supply power to any IEEE 802.3af/at compliant device(s).

• Electrical power is transmitted along with data in a single cable.
• It allows you to expand your network where there are electrical cables or outlets,
• where you wish to fix devices such as APs, IP Cameras, or IP Phones.

Overload Arrangement

TL-SG1008PE has a priority function that helps protect the system when its power is overloaded.

If all PoE devices’ power consumption is greater than or equal to 124W, a priority will be arranged among the 8 PoE ports, at which point the system will cut off the power of the lowest-priority port.

#image_title

Port Priority Function

This function helps protect the system if the power becomes overloaded.

For example, if ports 1, 2, 4, and 7 are using 30W (maximum power per port is 30W, the system power is 120W in total),

If there is an additional device inserted into Port 3 at 25W, the system will cut off the power of Port 7 in response to the power exceeding the 120W limit.,

This means Port 1, 2, and 4 will use 30W, and Port 3 will use 25W, with no power will be supplied to Port 7 as it has the lowest designated priority among the ports in use.

Easy To Use

• TL-SG1008PE is easy to install and use.
• It requires no configuration or installation.
• With its Desktop Rack-mountable design, outstanding performance, and quality, this gadget is a great choice for expanding your home or office network.
