Mikrotik hAP mini RB931-2nD Access Point /Router
KSh3,200.00 +Vat
Mikrotik hAP mini RB931-2nD Small 2GHz Wireless Access Point 3 x 10/100 Ethernet ports 650MHz CPU RouterOS
Mikrotik hAP mini RB931-2nD Access Point /Router
Mikrotik hAP mini RB931-2nD is a Small 2GHz Wireless Access Point with 3 x 10/100 Ethernet ports 650MHz CPU RouterOS
The hAP mini is a small 2GHz wireless access point for homes or small offices.
It has three ports, which are configured as one Internet port and two LAN ports, but can be reconfigured as desired, using the powerful RouterOS configuration options.
- The unit is powered by micro USB and measures only 8 cm tall.
- Even with its small size, the hAP mini is still quite powerful.
- It uses the QCA9533 CPU, just like the bigger units in the widely successful hAP series.
- The hAP mini (RB931-2nD) has an omnidirectional antenna built-in.
- It does not have a strict limitation on number of connected clients.
- It works in 2 GHz and supports 802.11b/g/n standards.
The powerful 650MHz CPU gives you full access to the wide variety of features provided by the versatile RouterOS operating system, but if all you want is a simple access point – it is already configured out of the box. You simply need to open it’s web configuration page and provide a password for it.
Mikrotik hAP mini RB931 Specification
| Details | |
|---|---|
| Product code | RB931-2nD |
| Architecture | SMIPS |
| CPU | QCA9533 |
| CPU core count | 1 |
| CPU nominal frequency | 650 MHz |
| Dimensions | 48 x 78 x 81mm |
| RouterOS license | 4 |
| Operating System | RouterOS |
| Size of RAM | 32 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 100’000 hours at 25C |
| Tested ambient temperature | -20°C to 70°C |
Wireless capabilities
| Details | |
|---|---|
| Wireless 2.4 GHz Max data rate | 300 Mbit/s |
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 1.5 |
| Wireless 2.4 GHz chip model | QCA9533 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
Certification & Approvals
| Details | |
|---|---|
| Certification | FCC, IC |
| IP | IP20 |
Mikrotik hAP mini RB931Â Wireless specifications
| 2.4 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 1MBit/s | 22 | -96 |
| 11MBit/s | 22 | -89 |
| 6MBit/s | 20 | -93 |
| 54MBit/s | 18 | -74 |
| MCS0 | 20 | -93 |
| MCS7 | 16 | -71 |
